- Model No.: LL-P500W
- Equivalent: 1000W High Pressure Sodium Lamp
- LED Light Source: CREE LED
- LED Luminous Efficiency: >130 lm/w (350mA/3V CREE XPE-R3 CW)
- Lamp Total Power: 500W
- Power Efficiency: > 95% ( TAIWAN MEAN WELL LED Driver UL/CB/PSE)
- Lamp Rated Luminous Flux (LED): > 50000lm
- Lamp Rated Luminous Efficiency: > 100 lm/w
- Color Rendering Index(CRI): Ra>70 (upgradeable to Ra90）
- Color Temperature: Cool white: 5700K-7000K
- Pure white: 4000-4500K
- Warm white: 2600-3700K
- Beam Angle: 5°, 10°,20°,30°,60°
- Light Distribution Curve(Beam Pattern): Asymmetric/ Rectangular Beam
- Input Voltage: AC 90-295V upgradeable to 305V
- Frequency Range: 47-63Hz
- Power Factor(PF): > 0.6
- Total Harmonic Distortion(THD): < 10%
- Storage Temperature: －40℃--+80℃
- Working Environment: －30℃--+50℃ ; 10%-95%RH
- Junction Temperature(Tj): 60℃ ± 10%(ta=25℃)
- Light Body and Lampshade Material: Aluminum Alloy and ASA / PC
- Working Lifetime: > 50,000hrs
- IP Rating: IP65
- Net Weight: 19.1kg
- Adopting Super Brightness original CREE High Power LED Lighting Source. Long lifespan, Energy saving, Environment friendly, High efficiency, No strobe, No ghosting, No UV or IR.
- Using high quality ASA industrial plastic shell outline for perfect lower and high temperature resistance.
- High efficiency Driver and very professional design, making the surface temperature of the light body below 60℃. The life span for the driver is over 30000 hours.
- Wide range for the Input Voltage, saying AC85V-265V/277V/305V/DC10-28V, can be used globally. Unique protection circuit and exact constant current system assure the abilities such as anti-interference and stability of the light.
- Automatically reduce current against overheating temperature.
- More aluminium heat sink cooling fins with best heat dissipation for guarantee longer lifespan of leds.
- Water-proof design (IP65).
- More than 70% energy saving.
LED Flood Light is widely used at skyscrapers, casino, supermarkets, bridges docks, TV towers and sculptures, construction sites, tower cranes, docks, squares, stadiums and other lighting places.
EXW, FOB Shenzhen
10-15days after order confirmation
